pINNACLE SErIES HIGH pEAK frAME TENT

Pinnacle Series High Peak Frame Tents are designed with a high
peak center mast supported by cross cables extending from each
corner fitting, maximizing the usable space underneath while at
the same time eliminating the need for interior frames or support
poles. The simple design allows for easy transportation, storage,
and installation involving only two people due to the reduced
amount of hardware in comparison to other frame or pole tents.
FREESTANDING - NO CENTER POLES FOR MAXIMUM AVAILABLE SPACE!

HIGH PEAK ALUMINUM
FLYING MAST CORNER FITTINGS PINNACLE SERIES HIGH PEAK FRAME TENTS C08/T08/H08

CROSS ALUMINUM
CABLES BASE PLATE

2” RATCHET 1” RATCHET TUBING
ASSEMBLY ASSEMBLY

Tent Construction:
• 16 oz (540 gsm) blockout, flame resistant, mold and mildew resistant vinyl
• All panels are bonded with 1” (25.4 mm) heat sealed overlapped seams
• 2 1/2” (63.5 mm) dia., 1/8” (3.17 mm) wall thickness, heavy-duty anodized aluminum
(6061-T6 aluminum) frame
• Cast aluminum corner fittings & base plates
• 95% of tent top is bonded with heat sealed construction
• Window and solid sidewall options
• Stock colors and custom printing available by special order
