Page 43 - layouthandbook

30’ x 30’ (9.1 m x 9.1 m) Master Series
4 3 2 1
Frame Tubing
1 Item Description Size Color Qty.
D 3 D Hip Rafter 21’10.5” (6.6 m) Red 4
7
6
3 2 Rafter 16’1” (4.9 m) Green 4
2
1 Spreader 14’4” (4.3 m) Red 8
4 Legs 7’8” (2.3 m) Black 8
5
369.96 in
[9396.89 mm]
OUTSIDE OF BASEPLATE 4
TO OUTSIDE OF BASEPLATE
8 Frame Fittings Sidewalls
Item Description Qty. Size Qty.
C C
5 Corner 4 20’ (6.1 m) ---
6 Side Tee w/ Ring 4 30’ (9.1 m) 4
7 8 Way Crown 1
Standard Pitch = 8’ (2.4 m) 8 Master Series 8 MASTER SERIES FRAME TENTS C07/T07/H07
Base Plates
R Pin/Pin & Bail 56
183.68 in 1” (25.4 mm) 8
B [4665.40 mm] B
BOTTOM OF BASEPLATE Master Series
97.20 in TO TOP OF RIDGE
[2468.75 mm] Ratchet Buckles
BOTTOM OF BASEPLATE
TO TOP OF EAVE
2” (50.8 mm) 8
371.13 in
[9426.70 mm] Ratchet Buckles
OUTSIDE OF BASEPLATE
TO OUTSIDE OF BASEPLATE
Stake/Anchors 16
PARTS LIST
ITEM QTY PART NUMBER DESCRIPTION
A 1 8 2AST172 14'4" (4.3 m) - Aluminum Single Tubing THESE PLANS AND SPECIFICATIONS ARE THE PROPERTY OF CELINA TENT, INC. AND SHALL NOT BE REPRODUCED WITHOUT THEIR WRITTEN PERMISSION. COPYRIGHT 2017 A
2 4 2AST193 16'1" (4.9 m)- Aluminum Single Tubing PRODUCT DESCRIPTION:
3 4 2AST262 21' 10.5" (6.7 m) Aluminum Single Tube 5373 STATE ROUTE 29
CELINA, OH 45822
4 8 2AST92 7'8" (2.3 m) - Aluminum Single Tubing PH: 419-586-3610 FAX: 419-584-0949
http://www.gettent.com
5 4 F01COR Corner Fitting DRAWN BY: TOLERANCE:
+/-1 in
6 4 F02STRING Side Tee with Ring Fitting PART NUMBER: Leslie [+/-25.40 mm]
7 1 F048WC 8 Way Crown Fitting 30'x30' Master Series Frame DRAWING UNITS: SHEET NUMBER: SHEET SIZE: REVISION: SCALE: DATE: WEBSITE SKU:
8 8 F39MB Master Tent Base Plate Fitting inches [mm] 1 C 1 / 70 8/10/2017
4 3 2 1
30’ x 45’ (9.1 m x 13.7 m) Master Series
4 3 2 1
Frame Tubing
Item Description Size Color Qty.
1
D 3 D Hip Rafter 21’10.5” (6.6 m) Red 4
7
3 2 Rafter 16’1” (4.9 m) Green 6
8
1 Spreader 14’4” (4.3 m) Red 11
2
6
4 Legs 7’8” (2.3 m) Black 10
4
549.96 in 9
[13968.89 mm]
OUTSIDE OF BASEPLATE Sidewalls
TO OUTSIDE OF BASEPLATE Frame Fittings
Item Description Qty. Size Qty.
C C
5 6 Corner 4 20’ (6.1 m) ---
7 Side Tee w/ Ring 6 30’ (9.1 m) 5
8 6 Way Crown 2
Standard Pitch = 8’ (2.4 m) 9 Master Series 10
Base Plates
5 30’ (9.1 m) Cable 2
B B
183.60 in R Pin/Pin & Bail 72
[4663.54 mm]
BOTTOM OF BASEPLATE
97.20 in TO TOP OF RIDGE
[2468.75 mm] 1” (25.4 mm) 10
BOTTOM OF BASEPLATE
TO TOP OF EAVE Master Series
Ratchet Buckles
371.13 in
[9426.70 mm] 2” (50.8 mm) 10
OUTSIDE OF BASEPLATE
TO OUTSIDE OF BASEPLATE
Ratchet Buckles
PARTS LIST
ITEM QTY PART NUMBER DESCRIPTION Stake/Anchors 20
1 11 2AST172 14'4" (4.3 m) - Aluminum Single Tubing
2 6 2AST193 16'1" (4.9 m)- Aluminum Single Tubing
A THESE PLANS AND SPECIFICATIONS ARE THE PROPERTY OF CELINA TENT, INC. AND SHALL NOT BE REPRODUCED WITHOUT THEIR WRITTEN PERMISSION. COPYRIGHT 2017 A
3 4 2AST262 21' 10.5" (6.7 m) Aluminum Single Tube
4 10 2AST92 7'8" (2.3 m) - Aluminum Single Tubing PRODUCT DESCRIPTION: 5373 STATE ROUTE 29 42
CELINA, OH 45822
CELINA TENT EUROPE LTD. / GETTENT.CO.UK / +44 115 794 0041
5 2 ACFTC1875X30CAR 3/16'' x 30' (4.8 mm x 9.1 m) Frame Tent Cable with Carabiners. PH: 419-586-3610 FAX: 419-584-0949
http://www.gettent.com
6 4 F01COR Corner Fitting DRAWN BY: TOLERANCE:
+/-1 in
7 6 F02STRING Side Tee with Ring Fitting PART NUMBER: Leslie [+/-25.40 mm]
8 2 F056WC 6 Way Crown Fitting 30'x45' Master Series Frame DRAWING UNITS: SHEET NUMBER: SHEET SIZE: REVISION: SCALE: DATE: WEBSITE SKU:
9 10 F39MB Master Tent Base Plate Fitting inches [mm] 1 C 1 / 80 8/10/2017
